DRS 710 Dry Running Seal
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Applications | Pharmaceutical & Food Industries. |
| Shaft Dia | 15 to 150 mm |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
ViewDry Running Seal DRS 710 Series is factory assembled & dynamic tested seal for steel, glass lined & SS mixers, agitators & vessels. It is a multiple spring externally mounted, reverse balanced seal with ‘O’ ring for secondary sealing.Various elastomers can be offered for different service applications. These seals are basically used on top entry agitators as dry running seals.When food products or pharmaceutical products are agitated in agitator, mixing of any other liquid will contaminate the product & affect it’s quality, hence these dry running seals are used. These seals do not require any external media for lubricating the faces and are therefore called dry running seals.
Seal Components/Face:
- Carbon / Silicon Carbide
- Carbon / Tungsten Carbide
- Silicon Carbide / Tungsten Carbide
- Secondary Seal : Elastomers, PTFE, TCV
- Metal Parts: SS304, SS316, Hastelloy-C, Hastelloy-B, Monel, Alloy-20
Seal Characteristics:
- Single Acting
- Reverse Balanced
- Outside Mounted
- Independent of Direction of Rotation
- Dry Running
